Highlights:
1. Navigation / GPS integrated in the device
2. Compatible with iPhone and Android smartphones, Mirror Link (mirror link) functions
3. Hands-free, Bluetooth and Wifi functions
(via mobile phone hotspot or external 3G/4G modem and SIM card)
4. Touch screen, USB ports and Playstore
5. The best multimedia/car radio with Android operating system
● Don't you want to take care of the installation? No problem. Just contact us please. We can do the installation for you professionally. ( Installation locations: Chur, Thun, Leuzigen, Oberengstringen, Reiden, Unterägeri, Mollis, Sins, Grüningen, Gais, Aeschlen, Nänikon, Trimbach, Bilten, Renens, Couvet, Ecuvillens, Moudon ).
Applicable models:
Kia Sportage(2010-2015)
System and hardware parameters
Operating system: Android 12.0 system
TFT drive IC: Rockchip PX30
CPU: Rockchip PX30, Cortex-A35, quad-core
Loader: SHINNY D-28HX-PWW-53X
RAM: DDR3 2GB
ROM: 16 GB
Screen: Capacitive and multi-touch screen
Screen: Hanstar Screen
Video decoder: 1080P HW
Power supply: 4 * 50W
Wifi: built-in
DVR: USB camera (PC standard)
Bluetooth: GOC-MD-6202A (1 DIN)
7OC-MD-705 (2 DIN)
Multimedia parameters
Music format: MP3.WMA.AAC.RM.LFAC etc
Video format: MPEG-1/2 / 4.H264.H263.VC1.RV.RMVB.DivX.Sorenson SparK.Spark.VP8.AVS Stream ...
Picture format: JPG / BMP / JEPG / GIF / PNG
radio parameters
Frequency range: FM: 76.0 MHz - 108.0 MHz
Frequency range: AM: 522 kHz - 1620 kHz
Country: China.Europe.Eastern.Russia.USA1.USA2.Japan
DVD parameters
Video output range: 1.0V - 1.2V (75Ω)
Compatible discs: DVD / DIVX / MP4 / MP3 / MP2 / VCD
amplifier parameters
Test voltage: 13.8V
Maximum output power: 4 * 50W
GPS parameters
Operating system: Android 10.0 system
Support Map: Android 10.0 Map
Main frequency: 1.6 GHz
Card solution: 800 * 480/1024 * 600
WIFI parameters
Power supply: Vcc_3.3V
Recommended Protocol / Standard: IEEE802.11B / g / n compatible WLAN
Interface type: USB2.0
Frequency: 2.4-2.484 GHz
RF power: 15 dBM
Modulation: OFDM / DBPSK / DQPSK / CCK
